Product Description

variety of connector products to fit most distribution applications. Installation methods may be automatic, bolted, or compression to connect various sizes and types of popular conductors (aluminum, copper, or bi-metallic) and support wires.

Product Tension Clamp 100-150mm Square
Test Items Test Content Test Result
Sample
1
Sample
2
Sample
3
Sample
4
Sample
5
Remarks
Visual  Inspection Crack 1)      Passed Mark"√"
2)  Not Passed Mark"×"
Test Conclusion:
Stoma Trachoma
Fins
Burr
Mechanical Characteristics Mechanical Load 1)Passed Mark"√"
2)Not Passed Mark"×"
Test Conclusion:
Inspector Date:  18. June,2010                        Approved:
S/N DETAILS UNITS DATA
1. Type
100mm2   Compression type mid span joint
complete with a tubular aluminium outer extrusion ,steel inner sleeve and two filler plugs
2. Material for outer
extrusion

Aluminium -99.5% purity
3. Material for inner sleeve
HDG steel
4. Type of inner sleeve
Tubular, suitable for compression into
hexagonal shape
5. Suitable for the following
ACSR Conductor Size
mm2 100
6. Resistivity
Less than 75% of  the resistivity of an
equivalent length of conductor.
7. Minimum failing load kN 35
8. Operating ambient
temperature
°C -1 to 40
9. Relative Humidity % 85
10. Altitude above sea level m 1400

CLAMP P/G ALUMINIUM/ALUMINIUM 100/100 MM2
S/N TYPE CONDUCTOR
CROSS SECTION AREAS (mm2)
NUMBER
AND MATERIAL OF BOLT
CLAMP
BODY MATERIAL
DIMENSI
ONS
1. Aluminium/Aluminiu
m conductor connection
100/100 2 X
Galvanised mild steel
bolts
Aluminium As per
Drawing
No.E11389 shown below

Other dimensions
2. Drawings showing
dimensions to be provided with bid
Yes/No Yes
3. Previous type tests
results/certificate to be provided with bid
Yes/No Yes
4. Quality assurance
certificate to be provided with bid
Yes/No Yes
5. Applicable standard
IEC standards
